AMD Ryzen 7 7700 5.3 GHz (Raphael) AM5 - tray without cooler

• 8 cores and 16 threads with only 65 watts TDP
• 3.8 GHz base clock and 5.3 GHz turbo clock, and overclocking thanks to an unlocked multiplier.
• PCIe 5.0 for lightning-fast data transfer and DDR5 with native 5,200 MHz
• Large cache memory for high gaming performance
• High performance and efficiency thanks to the 5-nanometer process
• Tray version without Wraith Prism CPU cooler!

AMD Ryzen 7 7700 – High-end performance based on Zen 4

The AMD Ryzen 7 7700 is based on the modern "Zen 4" architecture and offers 8 cores and 16 threads . Each core accesses the full L3 cache – perfect for gaming and multitasking. The CPU is part of the Raphael series and offers strong all-around performance for desktop PCs.

8 cores, 16 threads – up to 5.3 GHz Turbo

Thanks to Simultaneous Multithreading (SMT), the Ryzen 7 7700 processes up to 16 threads simultaneously. The base clock speed is 3.8 GHz , while Precision Boost 2 dynamically increases the clock speed to up to 5.3 GHz – with an efficient TDP of only 65 watts .

PCIe 5.0 & AM5 compatibility

With a compatible chipset, the Ryzen 7 7700 supports the PCI Express 5.0 standard – twice as fast as PCIe 4.0. All Ryzen 7000 processors use the new AM5 socket and are future-proof for modern motherboards and high-end graphics cards.

Advanced 5nm manufacturing process

The CPU cores are manufactured using a 5nm FinFET process with EUV technology. This allows for higher density and efficiency. It features 8 MB of L2 cache and 32 MB of L3 cache – ideal for gaming, rendering, and complex computing tasks.

I/O chiplet and 28 PCIe lanes

The I/O die is based on 6nm technology and manages the data connections. In total, the Ryzen 7 7700 offers 28 PCIe lanes : 4 for the chipset, 8 for NVMe SSDs, and 16 lanes for your graphics card – ideal for modern GPU setups.

Highest data rates with PCIe 5.0

In combination with an X670(E) or B650(E) motherboard, PCIe 5.0 offers maximum speed. Up to 15.6 GB/s is possible across four lanes – ideal for the latest generation of ultra-fast NVMe SSDs.

DDR5 RAM & modern connectors

The Ryzen 7 7700 supports DDR5 memory up to 5,200 MHz (native), and even higher speeds with overclocking. USB4, Thunderbolt 4 , and USB 3.2 Gen 2x2 are also available via the AM5 platform – with data transfer rates of up to 40 Gbps .

Precision Boost 2 – automatic overclocking

Thanks to Precision Boost 2, the CPU intelligently adjusts its clock speeds. Up to 150 MHz more than the normal boost is possible – provided the cooling and motherboard allow it. No manual overclocking is necessary.

Unlocked for manual overclocking

The Ryzen 7 7700 is fully unlocked . With a compatible motherboard (e.g., X670E or B650E ), you can freely adjust the multiplier – in the BIOS or with tools like Ryzen Master . Prerequisites: good VRMs and cooling.

Integrated Radeon graphics with RDNA2

The integrated Radeon GPU is based on RDNA2 and offers 2 Compute Units with 128 shaders and a clock speed of 2,200 MHz . It supports AV1, VP9, ​​H.264/H.265 , HDMI 2.1 and DisplayPort 2.0 – ideal for 4K and 8K displays.
